FS2F150 - Malco - 2 STATION BENDER, 150MM (1EA)

The Malco FS2F150 - 2 Station Bender (150mm) is a professional-grade, modular metal roofing bender designed for precision and efficiency on the jobsite. Here's a detailed overview:

Product Brochure

🔧 Product Overview

• Model: FS2F150
• Type: 2-Station Metal Roofing Bender
• Bend Width: 150 mm (5 7/8 inches)
• Design Purpose: Ideal for forming 0°–100° bends on straight panels of any length—perfect for gable ends, flashing, and standing seam panels.

📐 Bending Capabilities

• Bend Depth: 3/16″ to 5 7/8″ (5 mm – 150 mm)
• Bend Angle: 0° to 100°
• Bend Radius: 0.027″ (0.7 mm) standard; optional 2 mm with FSLR2 roller
• Material Thickness: Adjustable from 0.020″ to 0.040″ (0.5 – 1 mm)
• Compatible Materials:
  • 24-gauge steel
  • 26-gauge stainless steel
  • 0.040″ aluminum
  • 20 oz copper
  • 1 mm zinc

🛠️ Key Features

• Dual Station Design: Enables infinite-length bends with consistent pressure
• Adjustable Roller Spacing: From 0.5 mm to 1 mm for different material types
• Angled Rollers: Prevent scratching on 90° bends
• Durable Build: CNC-machined aluminum and stainless steel for corrosion resistance and stability
• Optional Accessories:
  • FSLR2: 2 mm large radius roller for softer bends
  • FSH2: Removable handle for compact storage
  • FSBAG2: Rolltop bag for transport and protection
