S-6415 - Henry - 1-5/8 ODS - 41mm - Muffler, Discharge Line

The Henry S-6621 Discharge Line Muffler is engineered to reduce noise and pulsation in the discharge lines of refrigeration and air-conditioning systems. Here's a detailed breakdown of its specifications:

Product: Henry S-6621 Discharge Line Muffler

• Connection Size: 2-1/8" ODS (Outside Diameter Solder)
• Body Diameter: 54 mm (approx. 2.13 inches)
• Length: 21 inches
• Weight: Approximately 18 lbs

Key Features

• Noise & Pulsation Reduction: Internal baffles alter the velocity of discharge gases, effectively dampening high-frequency sound waves and pulsations from both low- and high-speed compressors
• Bi-directional Flow: Allows flexible installation orientation
• Low Pressure Drop: Designed to minimize flow resistance while maintaining performance

Technical Specifications

• Maximum Working Pressure: 31 Barg (449.6 PSIG)
• Operating Temperature Range: 0°C to +121°C (+32°F to +249.8°F)
• Refrigerant Compatibility: CO₂, HCFC, HFC, and (for some models) A2L, HC, and HFO refrigerants where material compatibility is ensured
• Certifications: AS2971.2, CE, UKCA, UL207
