S-8490-HP - Henry - 168.3 x 381 - 5/8 ODS in X 5/8 ODS out - Receiver

The Henry S-8490-HP is a compact high-pressure vertical liquid refrigerant receiver, ideal for small refrigeration systems where space and capacity are limited. Here's a detailed breakdown of its specifications:

🔧 Technical Specifications

• Model: S-8490-HP
• Shell Dimensions:
  • Diameter: 168.3 mm (6.63 inches)
  • Length: 381 mm (15 inches)
• Inlet Connection: 5/8" ODS
• Outlet Connection: 5/8" ODS
• Mounting Orientation: Vertical
• Material: Heavy-duty steel
• Finish: Powder-coated for corrosion resistance
• Pressure Rating: High-pressure (typically up to 450 PSI)

⚙️ Functional Features

• Primary Function: Stores liquid refrigerant and ensures a steady, controlled supply to the expansion device.
• Design Features:
  • Compact vertical design for tight installations
